Hitachi air365 Max Pro
Key Info
| SmoothDrive 2.0 | : | This proprietary technology uses a high-precision inverter to control compressor speed in increments of 0.1 Hz. It improves part-load efficiency by up to 39% and ensures stable indoor temperatures by matching the load precisely. |
| airCloud Tap (NFC) | : | A built-in NFC chip allows technicians to configure and troubleshoot the outdoor unit via a smartphone app without opening the electrical cabinet. This can speed up commissioning by up to 4x. |
| Sigma (Σ) Heat Exchanger | : | Features a patented 3-way path structure and approximately 6,000 aluminum fins to maximize the heat-transfer area within a compact footprint. |
| Enhanced Comfort | : | Includes functions like GentleCool (prevents cold drafts) and CrowdSense (adjusts based on room occupancy). |
| Dual Mode | : | Operates as both a 2-pipe (Heat Pump) and 3-pipe (Heat Recovery) system, allowing for simultaneous heating and cooling in different zones when used with CH-Boxes. |
Content for Technical Specifications goes here. You can add tables, lists, and detailed information about the product's features.
| Cooling Capacity | 8 HP to 96 HP (Combined modules) |
| Refrigerant | R410A |
| Compressor Type | DC Inverter Scroll with Hot Gas Injection |
| Seasonal Efficiency (SEER) | Up to 8.38 (Pro model) |
| Seasonal Efficiency (SCOP) | Up to 5.19 (Pro model) |
| Operating Range (Cooling) | -10°C to +52°C |
| Operating Range (Heating) | -25°C to +15°C |
| Max Piping Length | Up to 1,000m (Total); 200m (Actual) |
| Height Difference | Up to 110m (between ODU and IDU) |
| External Static Pressure | Up to 80 Pa (Adjustable) |
| Indoor Unit Connection | Up to 200% of outdoor unit capacity |
